About

This post introduces Retrieval-Augmented Generation (RAG) using the llm.rb library. The example is only 32-lines of Ruby code 🫡 And best of all ? The post concludes with a live demo.

Context

For storage and retrieval, we’ll use OpenAI’s Vector Stores API as our vector database. If “RAG” or “vector database” are new terms for you, don’t worry – we’ll cover them both briefly before diving into the example. Our “knowledge base” or primary content will be composed of the files found in the documents/ directory, and it contains the FreeBSD handbook – with one file per chapter.

Background

What is RAG?

RAG is a technique whereby a language model is given extra context – retrieved from an external knowledge source – before generating a response. With RAG, you supply your own knowledge base at query time. The LLM then generates responses based entirely (or primarily) on that provided context, ensuring the answers are grounded in your chosen source of truth.

For example, an engineering team could load the company’s internal API docs into a RAG system. Queries about those APIs would return accurate, up-to-date answers, even if the model was trained long before those APIs existed.

What is a vector database?

A vector database is a common choice for storing and retrieving the context used in RAG. We will be dealing with a text-based vector database but it is worth knowing that vector databases can also handle images, audio, and other types of data.

Here’s the basic idea:

• Embeddings: Text is converted into a high-dimensional numeric representation (an “embedding”) that captures semantic meaning.
• Search: Given a query, the database compares embeddings to find the most semantically similar text chunks.
• Results: The most relevant chunks are returned and injected into the LLM’s prompt.

In RAG, these retrieved chunks form the knowledge base for that particular prompt. The LLM can then use them to answer questions, summarize, or otherwise respond with grounding in specific, relevant information.

Example

Explanation

The following example adds the contents of the documents/ directory by uploading them as files via OpenAI’s Files API. The next step is to create a vector store, and the vector store will be composed of the files that we just uploaded.

After the vector store is created, and it is ready, we can search the vector store with a query. The query will produce one or more chunks of text, and those chunks will be provided to the system prompt.

Finally, the bot will generate a response based on the system prompt and the user’s question. This is done in an infinite loop, so you can ask as many questions as you like, and the bot will respond with answers based on the context provided by the vector store.

require "llm"
require "erb"

llm   = LLM.openai(key: ENV["OPENAI_SECRET"])
bot   = LLM::Bot.new(llm)
docs  = Dir["documents/*.pdf"]
files = docs.map do
  print "[-] wait ", _1, "\n"
  llm.files.create(file: _1)
end
store = llm.vector_stores.create(name: "FreeBSD Handbook", file_ids: files.map(&:id))

print "[-] wait vector store", "\n"
while store.status != "completed"
  sleep(0.5)
  store = llm.vector_stores.get(vector: store)
end
print "[-] done!", "\n"

loop do
  print "> "
  query = $stdin.gets&.chomp || break
  res = llm.vector_stores.search(vector: store, query:)
  chunks = res.data.select { _1.score > 0.7 }
  bot.chat(stream: $stdout) do |prompt|
    prompt.system ERB.new(File.read("prompts/system.erb.txt")).result(binding)
    prompt.user(query)
  end.to_a
  print "\n"
rescue LLM::Error => e
  print e.class.to_s + ": " + e.message + "\n"
end

Demo

Start the demo
